XtraColl® applicator, extension insert.

Use our applicator to apply XtraColl® double-sided adhesive tape to the edge of the glass easily and accurately. By simply changing the insert, you can use the applicator for different glass thicknesses.Application note:Matching applicator BO 5207946N.Bohle Duplocoll® Adapter for Applicator Accessories for BO 5207939N · Tempered glass thickness 10–12 mm (BO 5207948)   Accessories for BO 5207946N · Glass thickness: toughened glass 8–10 mm · laminated glass 8.76 mm (BO 5207947)   Accessories for BO 5207946N · Glass thickness: laminated glass 17.52 mm (BO 5207949)

Use the accompanying XtraColl® applicator for easy and precise application to the edge of the glass.Use our applicator to apply XtraColl® double-sided adhesive tape to the edge of the glass easily and accurately. By changing the insert, you can use the applicator for different glass thicknesses.Application note:Matching extension inlay BO 5207947 for glass thicknesses ESG 8–10 mm; VSG 8.76 mm. Matching extension inlay BO 5207949 for glass thickness VSG 17.52 mm. Inlay BO 5207948, suitable for glass thicknesses of 10 and 12 mm, in combination with applicator BO 5207939N Inlay BO 5207947, suitable for glass thicknesses of 8, 8.76 and 10 mm, in combination with applicator BO 5207946N. Insert BO 5207949, suitable for glass thickness 17.52 mm, in combination with applicator BO 5207946N

XtraColl® is the ideal adhesive tape for sealing glass joints where transparency is important, for example in all-glass systems, glass partition walls, furniture construction or shower enclosures. Compared to silicone, you save a considerable amount of time and money during installation. The adhesive joints are barely visible because the tape’s refractive index is almost identical to that of glass. The adhesive-free dry edge makes XtraColl® resistant to external influences. It offers excellent initial adhesion and consistently high final strength. The adhesive tape is resistant to ageing and UV radiation; it is economical, high-quality and design-friendly. The adhesive tape can also be used on various materials such as glass, wood, aluminium, plastic or ceramics. Glass thickness: 8 – 8.76 mm – Width: 5 mm – Material thickness: 3 mm Glass thickness: 10 – 10.76 mm – Width: 7 mm – Material thickness: 3 mm Glass thickness: 12 – 12.76 mm – Width: 9 mm – Material thickness: 3 mm Glass thickness: 17.52 mm - Width: 14 mm - Material thickness: 3 mm Significant time and cost savings compared to sealing with silicone Ageing- and UV-resistant, economical, high-quality and design-friendly Clean and simple application process, particularly with the optional applicator Suitable for all kinds of materials such as wood, aluminium, plastic, ceramics or glass Temperature resistance: -40°C to +150°C When using XtraColl® on laminated safety glass with acoustic PVB film, suitability must be checked in advance. Use the accompanying applicator for easy and precise application to the edge of the glass. For glass thicknesses of 10 and 12 mm, use insert BO 5207948 in combination with applicator BO 5207939N. For glass thicknesses of 8, 8.76 and 10 mm, use insert BO 5207947 in combination with applicator BO 5207946N. Insert BO 5207949, suitable for a glass thickness of 17.52 mm, in combination with applicator BO 5207946N. To assist with sliding glass panes together, we recommend the BO 650.35 or BO 650.33 pane clamp. Click here for the brochure in PDF format:

XtraColl® is the ideal adhesive tape for sealing glass joints where transparency is important, for example in all-glass systems, glass partition walls, furniture construction or shower enclosures. Compared to silicone, you save a considerable amount of time and money during installation. The adhesive joints are barely visible because the tape’s refractive index is almost identical to that of glass. The adhesive-free dry edge makes XtraColl® resistant to external influences. It offers excellent initial adhesion and consistently high final strength. The adhesive tape is resistant to ageing and UV radiation; it is economical, high-quality and design-friendly. The adhesive tape can also be used on various materials such as glass, wood, aluminium, plastic or ceramics. Glass thickness: 8 – 8.76 mm – Width: 5 mm – Material thickness: 3 mm Glass thickness: 10 – 10.76 mm – Width: 7 mm – Material thickness: 3 mm Glass thickness: 12 – 12.76 mm – Width: 9 mm – Material thickness: 3 mm Glass thickness: 17.52 mm - Width: 14 mm - Material thickness: 3 mm Significant time and cost savings compared to sealing with silicone Ageing- and UV-resistant, economical, high-quality and design-friendly Clean and simple application process, particularly with the optional applicator Suitable for all kinds of materials such as wood, aluminium, plastic, ceramics or glass Temperature resistance: -40°C to +150°C When using XtraColl® on laminated safety glass with acoustic PVB film, suitability must be checked in advance. Use the accompanying applicator for easy and precise application to the edge of the glass. For glass thicknesses of 10 and 12 mm, use insert BO 5207948 in combination with applicator BO 5207939N. For glass thicknesses of 8, 8.76 and 10 mm, use insert BO 5207947 in combination with applicator BO 5207946N. Insert BO 5207949, suitable for a glass thickness of 17.52 mm, in combination with applicator BO 5207946N. To assist with sliding glass panes together, we recommend the BO 650.35 or BO 650.33 pane clamp. Click here for the brochure in PDF format:

XtraColl® is the ideal adhesive tape for sealing glass joints where transparency is important, for example in all-glass systems, glass partition walls, furniture construction or shower enclosures. Compared to silicone, you save a considerable amount of time and money during installation. The adhesive joints are barely visible because the tape’s refractive index is almost identical to that of glass. The adhesive-free dry edge makes XtraColl® resistant to external influences. It offers excellent initial adhesion and consistently high final strength. The adhesive tape is resistant to ageing and UV radiation; it is economical, high-quality and design-friendly. The adhesive tape can also be used on various materials such as glass, wood, aluminium, plastic or ceramics. Glass thickness: 8 – 8.76 mm – Width: 5 mm – Material thickness: 3 mm Glass thickness: 10 – 10.76 mm – Width: 7 mm – Material thickness: 3 mm Glass thickness: 12 – 12.76 mm – Width: 9 mm – Material thickness: 3 mm Glass thickness: 17.52 mm - Width: 14 mm - Material thickness: 3 mm Significant time and cost savings compared to sealing with silicone Ageing- and UV-resistant, economical, high-quality and design-friendly Clean and simple application process, particularly with the optional applicator Suitable for all kinds of materials such as wood, aluminium, plastic, ceramics or glass Temperature resistance: -40°C to +150°C When using XtraColl® on laminated safety glass with acoustic PVB film, suitability must be checked in advance. Use the accompanying applicator for easy and precise application to the edge of the glass. For glass thicknesses of 10 and 12 mm, use insert BO 5207948 in combination with applicator BO 5207939N. For glass thicknesses of 8, 8.76 and 10 mm, use insert BO 5207947 in combination with applicator BO 5207946N. Insert BO 5207949, suitable for a glass thickness of 17.52 mm, in combination with applicator BO 5207946N. To assist with sliding glass panes together, we recommend the BO 650.35 or BO 650.33 pane clamp. Click here for the brochure in PDF format:
